MAC97

ترایاک MAC97A6 پکیج TO-92

 General

Planar passivated very sensitive gate four quadrant triac in a SOT54 plastic package
intended to be interfaced directly to microcontrollers, logic integrated circuits and other
low power gate trigger circuits.

Features
• Direct interfacing to logic level ICs
• Direct interfacing to low power gate drivers and microcontrollers
• High blocking voltage capability
• Planar passivated for voltage ruggedness and reliability
• Triggering in all four quadrants
• Very sensitive gate

Specification

Product Category: Triacs
Non Repetitive On-State Current: 8.8 A
Rated Repetitive Off-State Voltage VDRM: 400 V
Off-State Leakage Current @ VDRM IDRM: 3 uA
On-State Voltage: 1.9 V
Holding Current Ih Max: 10 mA
Gate Trigger Voltage – Vgt: 2 V
Gate Trigger Current – Igt: 7 mA
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 125 C

Applications
• General purpose low power phase control
• General purpose low power switching
• Solid-state relay
